Volume pricing
- 1+ pcs$2.52
- 10+ pcs$2.37
- 100+ pcs$2.24
- 500+ pcs$2.11
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Filter Feature
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Mil Conformance
- NO
- Name Of Rows Loaded
- A,B,C
- Çalışma Sıcaklığı
- -40°C~105°C
- Pitch
- 0.100 2.54mm
- Reliability
- COMMERCIAL
- Number Of Pcb Rows
- 3
- Length Tail
- 4.5mm
- Pozisyon Sayısı
- 48
- Material Insulation
- Thermoplastic, Glass Filled
- Rated Current Signal
- 2A
- Ul Flammability Code
- 94V-0
- JESD-609 Kodu
- e4
- Uzunluk
- 54.9mm
- Akım Değeri
- 2A
- Orientation
- Straight
- Mating Contact Row Spacing
- 0.1 inch
- Polarization Key
- POLARIZED HOUSING
- Max Current Rating
- 2A
- Reference Standard
- UL
- Durability
- 400 Cycles
- Mixed Contacts
- NO
- Insulation Resistance
- 1000000000000Ohm
- RoHS Durumu
- ROHS3 Compliant
- Flammability Rating
- UL94 V-0
- Gender
- Female
- Level Class
- 2
- Kurşunsuz Kodu
- yes
- Option
- GENERAL PURPOSE
- Total Number Of Contacts
- 48
- Ambalaj
- Bulk
- Housing Material
- Thermoplastic
- Contact Resistance
- 15mOhm
- Contact Plating
- Gold
- Depth
- 10.5mm
- Connector Type
- Receptacle, Female Sockets
- Terminal
- Press-Fit
- Seri
- DIN 41612
- Montaj
- Through Hole
