C5822.18.01

Specifications

Dielectric Diameter

0.180 (4.57mm)

Parça Durumu

Active

Shield Material

Flexfoil®, Aluminum

Insulation Materials

PVC

Nem Hassasiyeti (MSL)

1 (Unlimited)

Wirecable Type

Coaxial

Shield Type

Foil, Braid

Cable Group

RG-6

Vop Velocity Of Propagation

85

Wirecable Gauge

18 AWG

Conductor Strand

Solid

Wire Gauge

18 AWG (0.82mm2)

Usage

LAN

Renk

Black

Jacket Insulation Material

Poly-Vinyl Chloride (PVC)

Uzunluk

500.0' 152.40m

RoHS Durumu

RoHS Compliant

Cable Types

Coaxial

Jacket Color

Black

Dielectric Material

Solid Polyethylene (PE)

Shield Coverage

100%, 60%

Empedans

75Ohms

Jacket Insulation Diameter

0.267 (6.78mm)

Insulation Diameter

6.7818 mm

Conductor Material

Steel, Copper Coated
