C5044.41.01

Specifications

Kılıf / Paket

100

Vop Velocity Of Propagation

85

Conductor Material

Steel, Copper Coated

Wirecable Gauge

14 AWG

Cable Group

RG-11

Fabrika Tedarik Süresi

6 Weeks

Jacket Insulation Diameter

0.405 (10.29mm)

Wire Gauge

14 AWG (2.08mm2)

Dielectric Diameter

0.280 (7.11mm)

Insulation Materials

PVC

Nem Hassasiyeti (MSL)

1 (Unlimited)

Jacket Color

Black

Conductor Strand

Solid

Usage

CATV

Jacket Insulation Material

Poly-Vinyl Chloride (PVC)

Empedans

75Ohms

Kurşunsuz

Lead Free

Özellikler

Quad Shield

Renk

Black

Montaj

Cable

Shield Type

Foil, Braid

Shield Material

Flexfoil®, Aluminum

Uzunluk

1000.0' 304.80m

RoHS Durumu

RoHS Compliant

Shield Coverage

100%, 61%, 100%, 40%

Insulation Diameter

10.287 mm

Cable Types

Coaxial

Dielectric Material

Cellular (Foam) Polyethylene (Cellular FPE)

Parça Durumu

Active

Wirecable Type

Coaxial
