C1156.41.01

Specifications

Cable Group

RG-174

Shield Type

Braid

Insulation Materials

PVC

Wirecable Type

Coaxial

Parça Durumu

Active

Insulation Diameter

2.6162 mm

Jacket Insulation Diameter

0.103 (2.62mm)

Shield Coverage

88%

Cable Types

Coaxial

Conductor Strand

7 Strands / 34 AWG

Shield Material

Copper, Tinned

Usage

RF Signal, Video

Uzunluk

1000.0' 304.80m

Empedans

50Ohms

Jacket Color

Black

Dielectric Material

Solid Polyethylene (PE)

Renk

Black

Vop Velocity Of Propagation

66

Jacket Insulation Material

Poly-Vinyl Chloride (PVC)

Dielectric Diameter

0.060 (1.52mm)

Nem Hassasiyeti (MSL)

1 (Unlimited)

RoHS Durumu

RoHS Compliant

Wirecable Gauge

26 AWG

Wire Gauge

26 AWG (0.14mm2)

Conductor Material

Steel, Copper Coated

Fabrika Tedarik Süresi

6 Weeks
