Volume pricing
- 1+ pcs$0.18
- 10+ pcs$0.17
- 100+ pcs$0.16
- 500+ pcs$0.15
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Length Termination
- 0.157 inch
- Parça Durumu
- Active
- Switch Function
- On-On
- Fabrika Tedarik Süresi
- 11 Weeks
- Contact Currentdcmax
- 0.1A
- ECCN Kodu
- EAR99
- Akım Değeri
- 100mA
- Yayın Yılı
- 2006
- Tip
- Standard
- Pcb Hole Count
- 6
- Voltage Rated Dc
- 30V
- Montaj
- Through Hole
- Actuator Travel
- 2.9972 mm
- Actuator Material
- POLYOXYMETHYLENE
- Actuator Type
- Plunger for Cap
- Body Height
- 14.7066mm
- Contact Dc Max Rating R Load
- 0.1A@30VDC
- Insulation Resistance
- 100000000Ohm
- Dielectric Withstanding Voltage
- 250VAC V
- Terminal
- PC Pin
- Center Contact Material
- COPPER ALLOY
- Circuit
- DPDT
- Actuator Length
- 0.413 inch
- Contact Resistance
- 0.1mOhm
- Montaj Tipi
- Through Hole, Right Angle
- RoHS Durumu
- ROHS3 Compliant
- Current Rating Amps
- 100mA DC
- Terminal Material
- COPPER ALLOY
- Housing Material
- POLYBUTYLENE TEREPHTHALATE
- Electricallife
- 10,000 Cycles
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Body Length Or Diameter
- 7.2898mm
- Throw Configuration
- DPDT, SPDT
- Mechanical Life
- 30,000 Cycles
- Ambalaj
- Bulk
- Insulation Materials
- POLYAMIDE
- Contact Plating
- Silver
- Body Breadth
- 9.0932 mm
- Seri
- PBH
- End Contact Material
- COPPER ALLOY
