Volume pricing
- 1+ pcs$3.46
- 10+ pcs$3.26
- 100+ pcs$3.08
- 500+ pcs$2.91
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Circuit
- SPDT
- Montaj
- Through Hole, Vertical
- Fabrika Tedarik Süresi
- 9 Weeks
- Montaj Tipi
- Through Hole, Right Angle, Vertical
- Voltage Rated Dc
- 20V
- Switch Function
- On-On
- Akım Değeri
- 400mA
- Electricallife
- 30,000 Cycles
- Kurşunsuz Kodu
- yes
- Contact Timing
- Not Specified
- Pozisyon Sayısı
- 2
- Contact Finish
- Gold
- Terminal
- PC Pin
- Contact Resistance
- 0.1mOhm
- Voltage Rated Ac
- 20V
- Body Breadth
- 6.604 mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Switch Type
- SLIDE SWITCH
- Pcb Hole Count
- 5
- Actuator Length
- 4.72mm
- Current Rating Amps
- 0.4VA AC/DC
- Body Length Or Diameter
- 12.7mm
- Seri
- 500
- Özellikler
- Epoxy Sealed Terminals
- Contact Currentacmax
- 2A
- Contact Voltageacmax
- 250V
- Length Termination
- 0.156 inch
- Mechanical Life
- 30,000 Cycles
- Terminal Stili
- PC Pin
- Insulation Resistance
- 1000000000Ohm
- Orientation
- Vertical
- Contact Current Rating
- 5A
- Çalışma Sıcaklığı
- -30°C~85°C
- Housing Material
- STAINLESS STEEL
- Actuator Material
- Polyamide (PA), Nylon
- Parça Durumu
- Active
- Contact Materials
- Copper Alloy
- Ambalaj
- Bulk
- Actuator Type
- Standard
- Flammability Rating
- UL94 V-0
