Volume pricing
- 1+ pcs$3.94
- 10+ pcs$3.71
- 100+ pcs$3.50
- 500+ pcs$3.31
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Orientation
- Vertical
- Insulation Resistance
- 1000000000Ohm
- Terminal Stili
- Wire Wrap
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -30°C~85°C
- Housing Material
- STAINLESS STEEL
- Actuator Material
- Polyamide (PA), Nylon
- Actuator Type
- Standard
- Ambalaj
- Bulk
- Contact Materials
- Copper Alloy
- Contact Ac Max Power Rating R Load
- 0.4VA@20VAC
- Dielectric Withstanding Voltage
- 1000VRMS V
- RoHS Durumu
- ROHS3 Compliant
- Switch Travel
- 2.16mm
- Yayın Yılı
- 2006
- Body Height
- 6.35mm
- Electricallife
- 30,000 Cycles
- Switch Function
- On-On
- Fabrika Tedarik Süresi
- 9 Weeks
- Montaj Tipi
- Through Hole
- ECCN Kodu
- EAR99
- Circuit
- SPDT
- Montaj
- Through Hole
- Body Breadth
- 6.604 mm
- Terminal
- Wire Wrap
- Contact Resistance
- 0.01mOhm
- Voltage Rated Ac
- 20V
- Contact Timing
- Not Specified
- Pozisyon Sayısı
- 1
- Contact Finish
- Gold
- Current Rating Amps
- 0.4VA AC/DC
- Pcb Hole Count
- 3
- Switch Type
- SLIDE SWITCH
- Actuator Length
- 5.08mm
- Insulation Materials
- DIALLYL PHTHALATE
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Mechanical Life
- 30,000 Cycles
- Length Termination
- 0.736 inch
- Özellikler
- Epoxy Sealed Terminals
- Seri
- 500
