Volume pricing
- 1+ pcs$4.29
- 10+ pcs$4.04
- 100+ pcs$3.81
- 500+ pcs$3.60
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- End Contact Material
- COPPER ALLOY
- Body Height
- 8.636mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Illumination
- Non-Illuminated
- ECCN Kodu
- EAR99
- Contact Plating
- Silver
- Terminal Material
- COPPER ALLOY
- Additional Feature
- APPROVAL UL, CSA
- Body Breadth
- 8.128 mm
- Circuit
- DPDT
- Body Length Or Diameter
- 9.144mm
- Switch Type
- TOGGLE SWITCH
- Fabrika Tedarik Süresi
- 9 Weeks
- Insulation Resistance
- 1000000000Ohm
- Actuator Type
- Standard Round
- Voltage Rated Dc
- 28V
- RoHS Durumu
- ROHS3 Compliant
- Akım Değeri
- 3A
- Current Rating Amps
- 3A AC/DC
- Terminal
- Solder
- Dielectric Withstanding Voltage
- 1000VRMS V
- Housing Material
- STAINLESS STEEL
- Voltage Rated Ac
- 120V
- Actuator Length
- 9.40mm
- Panel Cutout Dimensions
- Circular - 4.95mm Dia
- Length Termination
- 0.11 inch
- Electricallife
- 30,000 Cycles
- Yayın Yılı
- 2007
- Ambalaj
- Bulk
- Seri
- 200
- Contact Resistance
- 0.02mOhm
- Terminal Stili
- Solder Lug
- Bushing Length
- 0.22 inch
- Contact Current Rating
- 3A
- Parça Durumu
- Active
- Özellikler
- Epoxy Sealed Terminals
- Bushing Thread
- 10-48
- Çalışma Sıcaklığı
- -30°C~85°C
- Switch Function
- On-Off-On
- Center Contact Material
- COPPER ALLOY
