Specifications
- Montaj Tipi
- Panel Mount, Through Hole
- Kurşunsuz
- Lead Free
- Reliability
- COMMERCIAL
- Shell Material Finish
- Steel, Nickel Plated
- Terminal
- Solder
- Seri
- 628
- Contact Finish Thickness
- Flash
- Dielectric Material
- Polyester Thermoplastic
- Contact Finish
- Gold
- Dielectric Withstanding Voltage
- 1000VAC V
- Pcb Contact Pattern
- STAGGERED
- Parça Durumu
- Active
- Housing Material
- Polyester
- RoHS Durumu
- ROHS3 Compliant
- Contact Resistance
- 10mOhm
- Pozisyon Sayısı
- 25
- Connector Style
- D-Sub
- Bodyshell Style
- PLUG
- Ambalaj
- Tray
- Renk
- Black
- Akım Değeri
- 5A
- Flange Feature
- Mating Side, Female Screwlock (4-40)
- Yayın Yılı
- 2005
- Number Of Pcb Rows
- 2
- Contact Materials
- Phosphor Bronze
- Montaj
- Panel, Through Hole
- Additional Feature
- EXTENDED BODY
- Sıra Sayısı
- 2
- Connector Type
- Receptacle, Female Sockets
- Çalışma Sıcaklığı
- -55°C~105°C
- Shell Size Connector Layout
- 3 DB B
- Uzunluk
- 53mm
- Özellikler
- Board Lock, Shielded
- Total Number Of Contacts
- 25
- Mating Contact Pitch
- 0.109 inch
- Reference Standard
- UL
- Genişlik
- 12.6mm
- Yükseklik
- 12.1mm
- ECCN Kodu
- EAR99
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
