Specifications
- Çalışma Sıcaklığı
- -55°C~105°C
- Additional Feature
- STAMPED CONTACTS, STANDOFFS
- Number Of Pcb Rows
- 2
- Contact Materials
- Phosphor Bronze
- Yayın Yılı
- 2011
- Akım Değeri
- 5A
- Flange Feature
- Mating Side, Female Screwlock (4-40)
- Renk
- Black
- Body Breadth
- 0.494 inch
- Fabrika Tedarik Süresi
- 14 Weeks
- HTS Kodu
- 8536.69.40.30
- Insulation Resistance
- 5000000000Ohm
- Flammability Rating
- UL94 V-0
- Contact Type
- Signal
- Yükseklik
- 13.1mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- ECCN Kodu
- EAR99
- Reference Standard
- UL
- Özellikler
- Board Lock, Shielded
- Shell Size Connector Layout
- 2 DA A
- Dielectric Material
- Polyester Thermoplastic
- Seri
- 628
- Terminal
- Solder
- Shell Material Finish
- Steel, Nickel Plated
- Montaj Tipi
- Panel Mount, Through Hole
- Bodyshell Style
- PLUG
- Kılıf / Paket
- Metal
- Housing Material
- Polyester
- Parça Durumu
- Active
- Dielectric Withstanding Voltage
- 1000VAC V
- Pcb Contact Pattern
- STAGGERED
- Connector Type
- Receptacle, Female Sockets
- Sıra Sayısı
- 2
- Montaj
- Panel, Through Hole
- Material Flammability Rating
- UL94 V-0
- Rated Current Signal
- 5A
- Genişlik
- 12.6mm
- Mating Contact Pitch
- 0.108 inch
- Total Number Of Contacts
- 15
- Uzunluk
- 39.2mm
