Specifications
- Dielectric Material
- Polyester Thermoplastic
- Terminal
- Solder
- Plating
- Steel
- Fabrika Tedarik Süresi
- 14 Weeks
- Pcb Contact Pattern
- STAGGERED
- Yükseklik
- 13.1mm
- Shell Size Connector Layout
- 2 DA A
- Contact Finish Thickness
- Flash
- Contact Finish
- Gold
- Additional Feature
- STAMPED CONTACTS
- Number Of Ports
- 1
- Genişlik
- 12.6mm
- Insulation Resistance
- 5000000000Ohm
- Reference Standard
- UL
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Flammability Rating
- UL94 V-0
- Contact Type
- Signal
- Seri
- 627
- Pozisyon Sayısı
- 15
- RoHS Durumu
- ROHS3 Compliant
- Connector Style
- D-Sub
- Housing Material
- Polyester
- Yayın Yılı
- 2005
- Montaj
- Panel, Through Hole
- Sıra Sayısı
- 2
- Çalışma Sıcaklığı
- -55°C~105°C
- Max Current Rating
- 5A
- Body Breadth
- 0.494 inch
- Connector Type
- Plug, Male Pins
- Orientation
- Straight
- Contact Materials
- Brass
- Reliability
- COMMERCIAL
- Number Of Pcb Rows
- 2
- Pitch
- 2.74mm
- Material Flammability Rating
- UL94 V-0
- Akım Değeri
- 5A
- Renk
- Black
- Ambalaj
- Tube
- Kurşunsuz
- Lead Free
- ECCN Kodu
- EAR99
