Volume pricing
- 1+ pcs$0.30
- 10+ pcs$0.29
- 100+ pcs$0.27
- 500+ pcs$0.26
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Reach Svhc
- No SVHC
- Max Power Dissipation
- 200mW
- Maks. Çalışma Sıcaklığı
- 150°C
- Dc Current Gain Hfe Min Ic Vce
- 100 @ 10mA 1V
- Max Breakdown Voltage
- 40V
- Transition Frequency
- 300MHz
- Fabrika Tedarik Süresi
- 19 Weeks
- Number Of Elements
- 1
- Collector Emitter Voltage Vceo
- 300mV
- Yükseklik
- 350μm
- Pin Sayısı
- 6
- Collectoremitter Breakdown Voltage
- 40V
- Terminal Kaplaması
- Nickel/Palladium/Gold (Ni/Pd/Au)
- Gain Bandwidth Product
- 250MHz
- Element Configuration
- Dual
- Collector Base Voltage Vcbo
- -40V
- Uzunluk
- 1.3mm
- Vce Saturation Max Ib Ic
- 300mV @ 5mA, 50mA / 400mV @ 5mA, 50mA
- Collectoremitter Saturation Voltage
- -400mV
- JESD-609 Kodu
- e4
- ECCN Kodu
- EAR99
- Tepe Reflow Süresi (maks. sn)
- 40
- Yayın Yılı
- 2007
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Transistor Type
- NPN, PNP
- RoHS Durumu
- ROHS3 Compliant
- Radyasyon Dayanımı
- No
- Transistor Element Material
- SILICON
- Terminal Sayısı
- 6
- Pin Sayısı
- 6
- Max Collector Current
- 200mA
- Frequency Transition
- 300MHz 250MHz
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Active
- Polarity
- NPN, PNP
- Turn Off Timemax Toff
- 70ns
- Turn On Timemax Ton
- 250ns
- Montaj
- Surface Mount
- Temel Parça No
- MMDT3946
- Montaj Tipi
- Surface Mount
