Specifications
- Tepe Reflow Sıcaklığı (°C)
- 260
- Uzunluk
- 28.7mm
- Yükseklik
- 11.23mm
- Element Configuration
- Single
- Case Connection
- ISOLATED
- Number Of Phases
- 1
- Voltage Forward Vf Max If
- 1.2V @ 17.5A
- Montaj Tipi
- Through Hole
- JESD-609 Kodu
- e3
- Terminal Formu
- WIRE
- Peak Nonrepetitive Surge Current
- 400A
- Kurşunsuz
- Lead Free
- Reverse Voltage Dc
- 420V
- Kılıf / Paket
- 4-Square, MB-W
- Radyasyon Dayanımı
- No
- Max Surge Current
- 400A
- Terminal Pozisyonu
- UPPER
- Current Reverse Leakage Vr
- 10μA @ 600V
- Pin Sayısı
- 4
- Peak Reverse Current
- 10μA
- Genişlik
- 28.7mm
- RoHS Durumu
- ROHS3 Compliant
- Terminal Sayısı
- 4
- Forward Current
- 35A
- Pin Sayısı
- 4
- Average Rectified Current
- 35A
- Forward Voltage
- 1.2V
- Montaj
- Screw, Through Hole
- Max Repetitive Reverse Voltage Vrrm
- 600V
- Number Of Elements
- 1
- Ambalaj
- Bulk
- Diode Element Material
- SILICON
- Tepe Reflow Süresi (maks. sn)
- 40
- Terminal
- Through Hole
- Çalışma Sıcaklığı
- -55°C~150°C TJ
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Diode Type
- Single Phase
- Terminal Kaplaması
- Matte Tin (Sn)
- Parça Durumu
- Obsolete
