Volume pricing
- 1+ pcs$0.29
- 10+ pcs$0.27
- 100+ pcs$0.25
- 500+ pcs$0.24
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Pin Sayısı
- 4
- Yayın Yılı
- 2008
- Average Rectified Current
- 1.5A
- Voltage Forward Vf Max If
- 1.1V @ 1.5A
- RoHS Durumu
- ROHS3 Compliant
- Peak Reverse Current
- 5μA
- Element Configuration
- Single
- Reverse Voltage Dc
- 560V
- Number Of Elements
- 1
- Pin Sayısı
- 4
- Radyasyon Dayanımı
- No
- Tepe Reflow Sıcaklığı (°C)
- 260
- Voltage Rated Dc
- 800V
- Kılıf / Paket
- 4-SIP, KBP
- Max Surge Current
- 40A
- Kapasitans
- 20pF
- Uzunluk
- 14.75mm
- Montaj
- Through Hole
- Max Repetitive Reverse Voltage Vrrm
- 800V
- Çalışma Sıcaklığı
- -65°C~150°C TJ
- Terminal Kaplaması
- Matte Tin (Sn)
- Terminal
- Through Hole
- Case Connection
- ISOLATED
- Terminal Sayısı
- 4
- Diode Element Material
- SILICON
- Forward Voltage
- 1.1V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Peak Nonrepetitive Surge Current
- 40A
- Additional Feature
- UL RECOGNIZED
- Kurşunsuz Kodu
- no
- JESD-609 Kodu
- e3
- Diode Type
- Single Phase
- Current Reverse Leakage Vr
- 5μA @ 800V
- Number Of Phases
- 1
- Temel Parça No
- KBP08
- Output Current
- 1.5A
- Kurşunsuz
- Lead Free
- Genişlik
- 3.65mm
- Forward Current
- 1.5A
- Tepe Reflow Süresi (maks. sn)
- 40
