Specifications
- Peak Nonrepetitive Surge Current
- 50A
- Forward Current
- 1A
- Kurşunsuz Kodu
- no
- Terminal Pozisyonu
- DUAL
- Terminal Sayısı
- 4
- Çalışma Sıcaklığı
- -65°C~150°C TJ
- Reverse Voltage Dc
- 70V
- Terminal Kaplaması
- Matte Tin (Sn)
- Number Of Elements
- 1
- Max Surge Current
- 50A
- Tepe Reflow Sıcaklığı (°C)
- 260
- Voltage Forward Vf Max If
- 1.1V @ 1A
- Radyasyon Dayanımı
- No
- Pin Sayısı
- 4
- Temel Parça No
- DF01
- Pin Sayısı
- 4
- Current Reverse Leakage Vr
- 10μA @ 100V
- Weight
- 299.00242mg
- Montaj Tipi
- Surface Mount
- Max Repetitive Reverse Voltage Vrrm
- 100V
- JESD-609 Kodu
- e3
- Montaj
- Surface Mount
- Forward Voltage
- 1.1V
- Kurşunsuz
- Lead Free
- Yükseklik
- 3.4mm
- Uzunluk
- 8.51mm
- Yayın Yılı
- 2006
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Tepe Reflow Süresi (maks. sn)
- 40
- RoHS Durumu
- ROHS3 Compliant
- Terminal
- SMD/SMT
- Fabrika Tedarik Süresi
- 9 Weeks
- Output Currentmax
- 1A
- Parça Durumu
- Active
- Number Of Phases
- 1
- Additional Feature
- UL RECOGNIZED
- Peak Reverse Current
- 10μA
- Element Configuration
- Single
- Diode Type
- Single Phase
- Genişlik
- 6.5mm
