Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Voltage Rated Dc
- 30V
- Kurşunsuz
- Contains Lead
- Montaj Tipi
- Surface Mount
- Max Reverse Voltage Dc
- 30V
- Terminal Sayısı
- 3
- Peak Reverse Current
- 2μA
- Tepe Reflow Süresi (maks. sn)
- 10
- Output Currentmax
- 0.2A
- Montaj
- Surface Mount
- Current Reverse Leakage Vr
- 2μA @ 25V
- Temel Parça No
- BAT54AW
- Forward Voltage
- 1V
- Terminal Formu
- GULL WING
- Terminal Pozisyonu
- DUAL
- Number Of Elements
- 2
- Kapasitans
- 10pF
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Reverse Recovery Time
- 5 ns
- Diode Element Material
- SILICON
- REACH Uyumluluk Kodu
- unknown
- Current Average Rectified Io
- 200mA DC
- Pin Sayısı
- 3
- Peak Nonrepetitive Surge Current
- 600mA
- Voltage Forward Vf Max If
- 1V @ 100mA
- Parça Durumu
- Discontinued
- Max Repetitive Reverse Voltage Vrrm
- 30V
- Forward Current
- 200mA
- Ambalaj
- Tape & Reel (TR)
- Average Rectified Current
- 200mA
- Min. Çalışma Sıcaklığı
- -65°C
- Maks. Çalışma Sıcaklığı
- 125°C
- Akım Değeri
- 200mA
- HTS Kodu
- 8541.10.00.70
- Diode Configuration
- 1 Pair Common Anode
- Pin Sayısı
- 3
- Uzunluk
- 2.2mm
- Terminal
- SMD/SMT
- Speed
- Small Signal =< 200mA (Io), Any Speed
- Genişlik
- 1.35mm
- Operating Temperature Junction
- -65°C~125°C
