Specifications
- Overall Height
- 19.06mm
- Packing Method
- BULK
- Terminal Stili
- Wire Leads - 6 (152.40mm)
- Lens Color
- White
- Lens Transparency
- Diffused
- Terminal Sayısı
- 3
- Lamp Color
- Green, Red
- Millicandela Rating
- 8mcd Green, 5mcd Red
- Gerilim
- 2.3V Green 2.1V Red
- Kurşunsuz Kodu
- yes
- Panel Cutout Shape
- Round
- Lens Style
- Round with Domed Top
- Operating Temperature Min
- -20°C
- Lens Size
- 5mm T-1 3/4
- Yüzey Montaj
- NO
- JESD-609 Kodu
- e1
- Fonksiyon Sayısı
- 1
- Akım
- 30mA Green 30mA Red
- HTS Kodu
- 8541.40.20.00
- Parça Durumu
- Active
- Configuration
- COMMON CATHODE, 2 ELEMENTS
- Terminal Kaplaması
- Tin/Silver/Copper (Sn/Ag/Cu)
- Mounting Feature
- PANEL MOUNT
- Seri
- 559
- Operating Temperature Max
- 85°C
- Viewing Angle
- 65°
- Yayın Yılı
- 2015
- Additional Feature
- IC COMPATIBLE, HIGH RELIABILITY
- Luminous Intensity
- 5.0/8.0 mcd
- Wavelength Peak
- 565nm Green 635nm Red
- Colorwavelength
- 3-Color
- Fabrika Tedarik Süresi
- 10 Weeks
- Ratings
- Vf (Typ), If (Max)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Tip
- LED
- RoHS Durumu
- ROHS3 Compliant
- Panel Cutout Dimensions
- 0.25 (6.35mm)
