Volume pricing
- 1+ pcs$2.71
- 10+ pcs$2.56
- 100+ pcs$2.41
- 500+ pcs$2.27
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Lens Style
- Round with Domed Top
- Operating Temperature Min
- -55°C
- Lens Size
- 5mm T-1 3/4
- Yüzey Montaj
- NO
- JESD-609 Kodu
- e4
- Fonksiyon Sayısı
- 1
- Akım
- 30mA Green 40mA Red
- HTS Kodu
- 8541.40.20.00
- Parça Durumu
- Active
- Overall Height
- 19.06mm
- Packing Method
- BULK
- Terminal Stili
- Wire Leads - 6 (152.40mm)
- Terminal Sayısı
- 2
- Lamp Color
- Green, Red
- Millicandela Rating
- 40mcd Green, 90mcd Red
- Gerilim
- 2.1V Green 1.8V Red
- Kurşunsuz Kodu
- yes
- Panel Cutout Shape
- Round
- Luminous Intensity
- 60.0/20.0 mcd
- Wavelength Peak
- 565nm Green 660nm Red
- Colorwavelength
- Green/Red
- Fabrika Tedarik Süresi
- 10 Weeks
- Ratings
- Vf (Typ), If (Max)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Tip
- LED
- RoHS Durumu
- ROHS3 Compliant
- Panel Cutout Dimensions
- 0.25 (6.35mm)
- Configuration
- COMMON BIPOLAR TERMINAL, 2 ELEMENTS
- Terminal Kaplaması
- Copper/Nickel/Silver (Cu/Ni/Ag)
- Mounting Feature
- PANEL MOUNT
- Seri
- 559
- Operating Temperature Max
- 100°C
- Viewing Angle
- 60°
- Yayın Yılı
- 2014
- Additional Feature
- IC COMPATIBLE, HIGH RELIABILITY
