Volume pricing
- 1+ pcs$3.61
- 10+ pcs$3.41
- 100+ pcs$3.22
- 500+ pcs$3.03
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Packing Method
- BULK
- Overall Height
- 16mm
- Lens Transparency
- Diffused
- Terminal Stili
- Wire Leads - 6 (152.40mm)
- Terminal Sayısı
- 2
- Lamp Color
- Red
- Gerilim
- 1.7V
- Millicandela Rating
- 2.3mcd
- Panel Cutout Shape
- Round
- Kurşunsuz Kodu
- yes
- Operating Temperature Min
- -55°C
- Lens Style
- Round with Domed Top
- Yüzey Montaj
- NO
- Fonksiyon Sayısı
- 1
- JESD-609 Kodu
- e1
- Lens Size
- 5mm T-1 3/4
- HTS Kodu
- 8541.40.20.00
- Parça Durumu
- Active
- Akım
- 7mA
- Terminal Kaplaması
- Tin/Silver/Copper (Sn/Ag/Cu)
- Configuration
- SINGLE
- Viewing Angle
- 50°
- Mounting Feature
- PANEL MOUNT
- Seri
- 559
- Operating Temperature Max
- 100°C
- Additional Feature
- IC COMPATIBLE, HIGH RELIABILITY
- Yayın Yılı
- 2015
- Luminous Intensity
- 2.3 mcd
- Colorwavelength
- Red
- Wavelength Peak
- 635nm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ratings
- Vf (Typ), If (Max)
- Fabrika Tedarik Süresi
- 10 Weeks
- Panel Cutout Dimensions
- 0.25 (6.35mm)
- Tip
- LED
- RoHS Durumu
- ROHS3 Compliant
