Specifications
- Viewing Angle
- 60°
- Operating Temperature Max
- 85°C
- Seri
- 559
- Mounting Feature
- PANEL MOUNT
- Additional Feature
- UL RECOGNIZED
- Yayın Yılı
- 1998
- Terminal Kaplaması
- Tin/Silver/Copper (Sn/Ag/Cu)
- Configuration
- SINGLE WITH BUILT-IN RESISTOR
- Panel Cutout Dimensions
- 0.25 (6.35mm)
- Tip
- LED
- RoHS Durumu
- ROHS3 Compliant
- Wavelength Peak
- 583nm
- Luminous Intensity
- 8.0 mcd
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ratings
- DC
- Fabrika Tedarik Süresi
- 10 Weeks
- Gerilim
- 12V
- Millicandela Rating
- 8mcd
- Terminal Sayısı
- 2
- Lamp Color
- Yellow
- Panel Cutout Shape
- Round
- Kurşunsuz Kodu
- yes
- Packing Method
- BULK
- Overall Height
- 15.88mm
- Lens Transparency
- Diffused
- Terminal Stili
- Wire Leads - 14 (355.60mm)
- JESD-609 Kodu
- e1
- Fonksiyon Sayısı
- 1
- Yüzey Montaj
- NO
- Lens Size
- 5mm T-1 3/4
- Parça Durumu
- Active
- HTS Kodu
- 8541.40.20.00
- Akım
- 13mA
- Operating Temperature Min
- -20°C
- Lens Style
- Round with Domed Top
