Specifications
- Panel Cutout Shape
- Round
- Akım
- 10mA
- Gerilim
- 5V
- Lamp Color
- Yellow
- Fabrika Tedarik Süresi
- 10 Weeks
- Fonksiyon Sayısı
- 1
- Tcode
- T-1
- Yüzey Montaj
- NO
- Millicandela Rating
- 12.6mcd
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2015
- Packing Method
- BULK
- Overall Height
- 15mm
- Configuration
- SINGLE
- Operating Temperature Min
- -40°C
- Ratings
- DC
- Terminal Kaplaması
- Copper/Nickel/Silver (Cu/Ni/Ag)
- Terminal Sayısı
- 2
- Lens Style
- Round with Domed Top
- Terminal Stili
- Wire Leads - 6 (152.40mm)
- Wavelength Peak
- 585nm
- RoHS Durumu
- ROHS3 Compliant
- Tip
- LED
- Lens Size
- 3mm T-1
- Mounting Feature
- RADIAL MOUNT
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal Adımı
- 2.54mm
- Operating Temperature Max
- 85°C
- Luminous Intensity
- 12.6 mcd
- Viewing Angle
- 60°
- Panel Cutout Dimensions
- 0.16 (4.06mm)
- Additional Feature
- IC COMPATIBLE, HIGH RELIABILITY
- JESD-609 Kodu
- e4
- Parça Durumu
- Active
- HTS Kodu
- 8541.40.20.00
- Seri
- 558
