Volume pricing
- 1+ pcs$1.25
- 10+ pcs$1.18
- 100+ pcs$1.12
- 500+ pcs$1.05
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Tip
- LED
- Mounting Feature
- PANEL MOUNT
- Lens Size
- 3mm T-1
- Terminal Adımı
- 2.54mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Additional Feature
- IC COMPATIBLE, HIGH RELIABILITY
- Operating Temperature Max
- 85°C
- Luminous Intensity
- 16.0 mcd
- Panel Cutout Dimensions
- 0.16 (4.06mm)
- Viewing Angle
- 40°
- HTS Kodu
- 8541.40.20.00
- Seri
- 558
- JESD-609 Kodu
- e1
- Parça Durumu
- Active
- Terminal Kaplaması
- Tin/Silver/Copper (Sn/Ag/Cu)
- Terminal Sayısı
- 2
- Lens Style
- Round with Domed Top
- Terminal Stili
- Wire Leads - 6 (152.40mm)
- Lens Transparency
- Diffused
- Wavelength Peak
- 563nm
- RoHS Durumu
- ROHS3 Compliant
- Tcode
- T-1
- Yüzey Montaj
- NO
- Ratings
- Vf (Typ), If (Max)
- Operating Temperature Min
- -25°C
- Configuration
- SINGLE
- Millicandela Rating
- 16mcd
- Yayın Yılı
- 2015
- Kurşunsuz Kodu
- yes
- Packing Method
- BULK
- Overall Height
- 4.78mm
- Panel Cutout Shape
- Round
- Akım
- 25mA
- Gerilim
- 2.1V
- Lamp Color
- Green
- Fabrika Tedarik Süresi
- 10 Weeks
- Fonksiyon Sayısı
- 1
