Specifications
- Millicandela Rating
- 1.6mcd
- Overall Height
- 9.65mm
- Yayın Yılı
- 2007
- Forward Voltagemax
- 3V
- HTS Kodu
- 8541.40.20.00
- Terminal Adımı
- 2.54mm
- Operating Temperature Min
- -55°C
- Montaj Tipi
- Through Hole, Right Angle
- Ambalaj
- Bulk
- Akım
- 2mA
- Tcode
- T-1
- Lens Style
- Round with Domed Top
- Configuration
- 2 High
- Packing Method
- BAG
- RoHS Durumu
- ROHS3 Compliant
- Mounting Feature
- RADIAL MOUNT
- Number Of Leds
- 2
- Fonksiyon Sayısı
- 2
- Luminous Intensitymin
- 0.0022 cd
- JESD-609 Kodu
- e4
- Operating Temperature Max
- 100°C
- Lens Size
- 3mm T-1
- Renk
- Red (x 1), Yellow (x 1)
- Terminal Kaplaması
- Copper/Nickel/Silver (Cu/Ni/Ag)
- Wavelength Peak
- 635nm 583nm
- Additional Feature
- HIGH RELIABILITY
- Fabrika Tedarik Süresi
- 10 Weeks
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Luminous Intensity
- 10.0/6.3 mcd
- Parça Durumu
- Active
- Nominal Gerilim
- 2V Red 2.1V Yellow
- Terminal Sayısı
- 4
- Lens Type
- Diffused, Tinted
- Optoelectronic Device Type
- DUAL COLOR LED ARRAY
- Yüzey Montaj
- NO
- Seri
- 553
- Kurşunsuz Kodu
- yes
