Specifications
- Viewing Angle
- 200 deg
- Lens Transparency
- Diffused
- Terminal Kaplaması
- Copper/Nickel/Silver (Cu/Ni/Ag)
- Yayın Yılı
- 2002
- Fabrika Tedarik Süresi
- 10 Weeks
- HTS Kodu
- 8541.40.20.00
- Overall Height
- 4.45mm
- Configuration
- COMMON BIPOLAR TERMINAL, 2 ELEMENTS
- Kılıf / Paket
- Radial
- Terminal Sayısı
- 2
- Peak Wavelength
- 660/565 nm
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Active
- Montaj Tipi
- Through Hole
- Ambalaj
- Bulk
- Millicandela Rating
- 3.7mcd Green, 12.6mcd Red
- RoHS Durumu
- ROHS3 Compliant
- Operating Temperature Max
- 100°C
- Forward Voltagemax
- 2.4V
- Forward Currentmax
- 0.04A
- Seri
- 521
- Lens Style
- Round with Domed Top
- Optoelectronic Device Type
- DUAL COLOR LED
- Tcode
- T-1
- Current Test
- 20mA Green 20mA Red
- Yüzey Montaj
- NO
- Luminous Intensity
- 12.6/3.7 mcd
- Lens Color
- White
- Terminal Adımı
- 2.54mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Height Max
- 5.70mm
- JESD-609 Kodu
- e4
- Lens Size
- 3.00mm Dia
- Fonksiyon Sayısı
- 1
- Operating Temperature Min
- -55°C
- Renk
- Green, Red
