Specifications
- Onay Kuruluşu
- CCC, CE, cULus, GS, PSE, RCM
- No Load Power Consumption
- 100mW Max
- Adapter Color
- Black
- Power Indicator
- No
- Isolation Voltage Min
- 3000VAC(TYP)(V)
- Load Regulation
- 5%(TYP)(%)
- Kurşunsuz
- Lead Free
- Product Depth Mm
- 34.5(mm)
- Output Connector
- USB A Receptacle
- Output Current
- 1(A)
- Weight
- 0.177lb 80.29g
- Max Power Dissipation
- 5W
- Efficiency
- Level VI, CoC Tier 2
- Line Regulation
- 5%(TYP)(%)
- Çıkış Gerilimi
- 5V
- Kullanım Bölgesi
- International
- RoHS Durumu
- RoHS Compliant
- Form
- Wall Mount (Class II)
- Operating Temp Range
- 0C to 40C
- Montaj Stili
- Plug-In
- Output Power
- 5(W)
- Boyut / Ölçü
- 1.85Lx1.36W x 1.04 H 47.0mmx34.5mmx26.4mm
- Input Frequency
- 47 to 63(Hz)
- Tip
- Regulated
- Güç (Watt)
- 5W
- Nem Hassasiyeti (MSL)
- Not Applicable
- Product Length Mm
- 47(mm)
- Input Voltage
- 90 to 264(V)
- Yayın Yılı
- 2015
- Product Height Mm
- 26.5(mm)
- Number Of Outputs
- 1
- Çalışma Sıcaklığı
- 0°C~40°C
- Seri
- SMI5-USB (5W)
- Applications
- ITE (Commercial)
- Output Connector Type
- USB
- Connector Type
- Receptacle, USB
- Usage Level
- Commercial grade
- Ripple Noise
- 300MV(MAX)(%)
- Style
- WallMount
- Output Voltage
- 5(V)
