Volume pricing
- 1+ pcs$0.57
- 10+ pcs$0.54
- 100+ pcs$0.51
- 500+ pcs$0.48
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Package Cooled
- TO-220
- Nominal Cross Section
- 1.5 - 1.5
- Gross Weight
- 6.8g
- Power Dissipation Temperature Rise
- 6.8W @ 75°C
- Uzunluk
- 1.450 36.83mm
- Nem Hassasiyeti (MSL)
- Not Applicable
- Ihs Manufacturer
- CUI DEVICES
- Thermal Resistance Forced Air Flow
- 3.47°C/W @ 200 LFM
- Attachment Method
- Bolt On
- Tip
- Board Level
- Fabrika Tedarik Süresi
- 11 Weeks
- Parça Durumu
- Active
- Yükseklik
- 21.59mm
- Thermal Resistance200 Lfm
- 3.47°C/W
- Shape
- Rectangular, Fins
- Height Off Base Height Of Fin
- 0.850 21.60mm
- Applications
- TO220
- Rohs Code
- Yes
- RoHS Durumu
- RoHS Compliant
- Type Of Heatsink
- extruded
- REACH Uyumluluk Kodu
- compliant
- Thermal Resistance
- max. 14.33°C/W
- Colour
- black
- Seri
- HSS
- Bolt Dimension Metric
- 3
- Üretici Parça No
- HSS-B20-NP-12
- Material Finish
- Black Anodized
- Base Thickness
- 1mm
- Material
- Aluminum
- Thermal Resistance Natural
- 14.33°C/W
- Material Finishing
- anodized
- Part Life Cycle Code
- Active
- Mounting
- screw
- Certificates
- RoHS compliant
- Heatsink Shape
- U
- Risk Rank
- 1.59
- Genişlik
- 0.700 17.80mm
