Volume pricing
- 1+ pcs$0.48
- 10+ pcs$0.45
- 100+ pcs$0.43
- 500+ pcs$0.40
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Material Finish
- Black Anodized
- Üretici Parça No
- HSS-B20-NP-10
- Material Finishing
- anodized
- Part Life Cycle Code
- Active
- Thermal Resistance Natural
- 25.92°C/W
- Base Thickness
- 800µm
- Material
- Aluminum
- Heatsink Shape
- U
- Certificates
- RoHS compliant
- Mounting
- PCB
- Risk Rank
- 2.16
- Genişlik
- 0.504 12.80mm
- Ihs Manufacturer
- CUI DEVICES
- Uzunluk
- 0.748 19.00mm
- Nem Hassasiyeti (MSL)
- Not Applicable
- Power Dissipation Temperature Rise
- 2.9W @ 75°C
- Gross Weight
- 13.6g
- Package Cooled
- TO-220
- Yükseklik
- 12.7mm
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 11 Weeks
- Tip
- Board Level
- Thermal Resistance Forced Air Flow
- 7.24°C/W @ 200 LFM
- RoHS Durumu
- RoHS Compliant
- Rohs Code
- Yes
- Applications
- TO220
- Height Off Base Height Of Fin
- 0.500 12.70mm
- Shape
- Rectangular, Fins
- Thermal Resistance200 Lfm
- 7.24°C/W
- Seri
- HSS
- Thermal Resistance
- max. 30.86°C/W
- Colour
- black
- REACH Uyumluluk Kodu
- compliant
- Type Of Heatsink
- extruded
