Volume pricing
- 1+ pcs$0.54
- 10+ pcs$0.51
- 100+ pcs$0.48
- 500+ pcs$0.45
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Seri
- HSS
- Thermal Resistance
- max. 31.07°C/W
- Colour
- black
- Type Of Heatsink
- extruded
- Applications
- TO220
- RoHS Durumu
- RoHS Compliant
- Thermal Resistance200 Lfm
- 5.72°C/W
- Height Off Base Height Of Fin
- 0.748 19.00mm
- Shape
- Rectangular, Fins
- Yükseklik
- 2.7mm
- Fabrika Tedarik Süresi
- 11 Weeks
- Parça Durumu
- Active
- Thermal Resistance Forced Air Flow
- 5.72°C/W @ 200 LFM
- Attachment Method
- PC Pin
- Tip
- Board Level, Vertical
- Power Dissipation Temperature Rise
- 2.9W @ 75°C
- Gross Weight
- 14.56g
- Package Cooled
- TO-220
- Nem Hassasiyeti (MSL)
- Not Applicable
- Uzunluk
- 0.512 13.00mm
- Genişlik
- 0.512 13.00mm
- Heatsink Shape
- U
- Certificates
- RoHS compliant
- Mounting
- PCB
- Material Finishing
- anodized
- Base Thickness
- 800µm
- Material
- Aluminum
- Thermal Resistance Natural
- 25.86°C/W
- Material Finish
- Black Anodized
