Volume pricing
- 1+ pcs$0.70
- 10+ pcs$0.66
- 100+ pcs$0.62
- 500+ pcs$0.58
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Risk Rank
- 2.16
- Genişlik
- 0.504 12.80mm
- Certificates
- RoHS compliant
- Mounting
- screw
- Heatsink Shape
- U
- Base Thickness
- 800µm
- Material
- Aluminum
- Thermal Resistance Natural
- 18.63°C/W
- Material Finishing
- anodized
- Part Life Cycle Code
- Active
- Material Finish
- Black Anodized
- Üretici Parça No
- HSS-B20-061H
- Type Of Heatsink
- extruded
- REACH Uyumluluk Kodu
- compliant
- Seri
- HSS
- Thermal Resistance
- max. 23.05°C/W
- Colour
- black
- Thermal Resistance200 Lfm
- 5.01°C/W
- Height Off Base Height Of Fin
- 0.500 12.70mm
- Shape
- Rectangular, Fins
- Rohs Code
- Yes
- Applications
- TO220
- RoHS Durumu
- RoHS Compliant
- Thermal Resistance Forced Air Flow
- 5.01°C/W @ 200 LFM
- Tip
- Board Level, Vertical
- Attachment Method
- PC Pin
- Yükseklik
- 12.7mm
- Fabrika Tedarik Süresi
- 11 Weeks
- Parça Durumu
- Active
- Power Dissipation Temperature Rise
- 4.0W @ 75°C
- Gross Weight
- 3.1g
- Package Cooled
- TO-220
- Nem Hassasiyeti (MSL)
- Not Applicable
- Uzunluk
- 1.500 38.10mm
- Ihs Manufacturer
- CUI DEVICES
