Specifications
- Risk Rank
- 5.57
- Shape
- Rectangular, Fins
- RoHS Durumu
- RoHS Compliant
- Heatsink Shape
- H
- REACH Uyumluluk Kodu
- compliant
- Mounting
- clip-on
- Material Finish
- Black Anodized
- Base Thickness
- 2mm
- Thermal Resistance200 Lfm
- 2.88°C/W
- Type Of Heatsink
- extruded
- Height Off Base Height Of Fin
- 1.000 25.40mm
- Ürün Durumu
- Active
- Material
- Aluminum Alloy
- Thermal Resistance Natural
- 6.15°C/W
- Colour
- black
- Seri
- HSE
- Gross Weight
- 35.56g
- Thermal Resistance Forced Air Flow
- 2.88°C/W @ 200 LFM
- Package Cooled
- TO-220
- Fabrika Tedarik Süresi
- 11 Weeks
- Material Finishing
- anodized
- Thermal Resistance
- max. 8.05°C/W
- Parça Durumu
- Active
- Part Life Cycle Code
- Active
- Tip
- Board Level, Vertical
- Certificates
- RoHS compliant
- Rohs Code
- Yes
- Uzunluk
- 1.969 50.00mm
- Attachment Method
- PC Pin
- Ihs Manufacturer
- CUI DEVICES
- Genişlik
- 1.378 35.00mm
- Yükseklik
- 25.4mm
- Power Dissipation Temperature Rise
- 12.2W @ 75°C
- Applications
- TO220
- Üretici Parça No
- HSE-B500-04H
- Nem Hassasiyeti (MSL)
- Not Applicable
- Paket
- Bulk
