Specifications
- REACH Uyumluluk Kodu
- compliant
- Heatsink Shape
- grilled
- RoHS Durumu
- RoHS Compliant
- Shape
- Rectangular, Fins
- Risk Rank
- 2.17
- Height Off Base Height Of Fin
- 0.630 16.00mm
- Type Of Heatsink
- extruded
- Thermal Resistance200 Lfm
- 4.93°C/W
- Material Finish
- Black Anodized
- Mounting
- screw
- Seri
- HSE
- Colour
- black
- Thermal Resistance Natural
- 15.96°C/W
- Material
- Aluminum Alloy
- Thermal Resistance
- max. 16.65°C/W
- Fabrika Tedarik Süresi
- 11 Weeks
- Material Finishing
- anodized
- Package Cooled
- TO-218, TO-220
- Gross Weight
- 9.5g
- Thermal Resistance Forced Air Flow
- 4.93°C/W @ 200 LFM
- Part Life Cycle Code
- Active
- Tip
- Board Level, Vertical
- Parça Durumu
- Active
- Attachment Method
- PC Pin
- Uzunluk
- 1.000 25.40mm
- Rohs Code
- Yes
- Certificates
- RoHS compliant
- Applications
- TO218
- Nem Hassasiyeti (MSL)
- Not Applicable
- Üretici Parça No
- HSE-B254-04H
- Power Dissipation Temperature Rise
- 4.7W @ 75°C
- Yükseklik
- 16mm
- Genişlik
- 0.650 16.50mm
- Ihs Manufacturer
- CUI DEVICES
- Application1
- TO220
