Specifications
- RoHS Durumu
- RoHS Compliant
- Heatsink Shape
- H
- Shape
- Rectangular, Fins
- Type Of Heatsink
- extruded
- Height Off Base Height Of Fin
- 0.500 12.70mm
- Mounting
- screw
- Thermal Resistance200 Lfm
- 5.17°C/W
- Base Thickness
- 1.57mm
- Material Finish
- Black Anodized
- Thermal Resistance Natural
- 9.62°C/W
- Seri
- HSE
- Colour
- black
- Material
- Aluminum Alloy
- Fabrika Tedarik Süresi
- 11 Weeks
- Material Finishing
- anodized
- Thermal Resistance
- max. 12.98°C/W
- Package Cooled
- TO-220
- Thermal Resistance Forced Air Flow
- 5.17°C/W @ 200 LFM
- Gross Weight
- 22.22g
- Tip
- Board Level, Vertical
- Parça Durumu
- Active
- Certificates
- RoHS compliant
- Attachment Method
- PC Pin
- Uzunluk
- 2.000 50.80mm
- Applications
- TO220
- Nem Hassasiyeti (MSL)
- Not Applicable
- Power Dissipation Temperature Rise
- 7.8W @ 75°C
- Yükseklik
- 12.7mm
- Genişlik
- 1.375 34.93mm
