Specifications
- Package Cooled
- TO-220
- Gross Weight
- 16.25g
- Thermal Resistance Forced Air Flow
- 2.67°C/W @ 200 LFM
- Material Finishing
- anodized
- Fabrika Tedarik Süresi
- 11 Weeks
- Thermal Resistance
- max. 10.51°C/W
- Material
- Aluminum Alloy
- Thermal Resistance Natural
- 10.71°C/W
- Seri
- HSE
- Colour
- black
- Mounting
- screw
- Material Finish
- Black Anodized
- Base Thickness
- 1.57mm
- Thermal Resistance200 Lfm
- 2.67°C/W
- Type Of Heatsink
- extruded
- Height Off Base Height Of Fin
- 0.500 12.70mm
- Shape
- Rectangular, Fins
- RoHS Durumu
- RoHS Compliant
- Heatsink Shape
- H
- Genişlik
- 1.378 35.00mm
- Applications
- TO220
- Nem Hassasiyeti (MSL)
- Not Applicable
- Power Dissipation Temperature Rise
- 7.0W @ 75°C
- Yükseklik
- 12.7mm
- Certificates
- RoHS compliant
- Attachment Method
- PC Pin
- Uzunluk
- 1.500 38.10mm
- Parça Durumu
- Active
- Tip
- Board Level, Vertical
