Specifications
- RoHS
- Yes
- Thermal Resistance
- max. 15.42°C/W
- Fabrika Tedarik Süresi
- 11 Weeks
- Material Finishing
- anodized
- Package Cooled
- TO-220
- Thermal Resistance Forced Air Flow
- 2.91°C/W @ 200 LFM
- Gross Weight
- 13.19g
- Seri
- HSE
- Colour
- black
- Thermal Resistance Natural
- 12.10°C/W
- Material
- Aluminum Alloy
- Height Off Base Height Of Fin
- 0.472 12.00mm
- Type Of Heatsink
- extruded
- Thermal Resistance200 Lfm
- 2.91°C/W
- Base Thickness
- 2.5mm
- Material Finish
- Black Anodized
- Mounting
- screw
- REACH Uyumluluk Kodu
- compliant
- Heatsink Shape
- U
- RoHS Durumu
- RoHS Compliant
- Risk Rank
- 5.29
- Shape
- Rectangular, Fins
- Applications
- TO220
- Üretici Parça No
- HSE-B20350-NP
- Nem Hassasiyeti (MSL)
- Not Applicable
- Yükseklik
- 12mm
- Power Dissipation Temperature Rise
- 6.2W @ 75°C
- Genişlik
- 1.142 29.00mm
- Ihs Manufacturer
- CUI DEVICES
- Attachment Method
- Bolt On
- Uzunluk
- 1.378 35.00mm
- Rohs Code
- Yes
- Certificates
- RoHS compliant
- Tip
- Board Level
- Part Life Cycle Code
- Active
- Parça Durumu
- Active
