Volume pricing
- 1+ pcs$2.48
- 10+ pcs$2.34
- 100+ pcs$2.20
- 500+ pcs$2.08
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Material
- Aluminum Alloy
- Thermal Resistance Natural
- 5.86°C/W
- Seri
- HSE
- Colour
- black
- Thermal Resistance Forced Air Flow
- 2.45°C/W @ 200 LFM
- Gross Weight
- 56.67g
- Package Cooled
- TO-218
- Material Finishing
- anodized
- Fabrika Tedarik Süresi
- 11 Weeks
- Thermal Resistance
- max. 7.62°C/W
- Shape
- Rectangular, Fins
- RoHS Durumu
- RoHS Compliant
- Heatsink Shape
- H
- Mounting
- screw
- Material Finish
- Black Anodized
- Base Thickness
- 1.5mm
- Thermal Resistance200 Lfm
- 2.45°C/W
- Type Of Heatsink
- extruded
- Height Off Base Height Of Fin
- 0.984 25.00mm
- Genişlik
- 1.654 42.00mm
- Yükseklik
- 25mm
- Power Dissipation Temperature Rise
- 12.8W @ 75°C
- Applications
- TO218
- Nem Hassasiyeti (MSL)
- Not Applicable
- Parça Durumu
- Active
- Tip
- Board Level, Vertical
- Certificates
- RoHS compliant
- Uzunluk
- 2.000 50.80mm
- Attachment Method
- PC Pin
