Specifications
- Attachment Method
- PC Pin
- Uzunluk
- 1.000 25.40mm
- Rohs Code
- Yes
- Certificates
- RoHS compliant
- Part Life Cycle Code
- Active
- Tip
- Board Level, Vertical
- Parça Durumu
- Active
- Applications
- TO218
- Nem Hassasiyeti (MSL)
- Not Applicable
- Üretici Parça No
- HSE-B18254-035H-00
- Power Dissipation Temperature Rise
- 10.0W @ 75°C
- Yükseklik
- 25mm
- Genişlik
- 1.638 41.60mm
- Ihs Manufacturer
- CUI DEVICES
- Height Off Base Height Of Fin
- 0.984 25.00mm
- Type Of Heatsink
- extruded
- Thermal Resistance200 Lfm
- 4.03°C/W
- Base Thickness
- 1.5mm
- Material Finish
- Black Anodized
- Mounting
- screw
- REACH Uyumluluk Kodu
- compliant
- Heatsink Shape
- H
- RoHS Durumu
- RoHS Compliant
- Shape
- Rectangular, Fins
- Risk Rank
- 2.16
- Thermal Resistance
- max. 8.51°C/W
- Fabrika Tedarik Süresi
- 11 Weeks
- Material Finishing
- anodized
- Package Cooled
- TO-218
- Gross Weight
- 23.33g
- Thermal Resistance Forced Air Flow
- 4.03°C/W @ 200 LFM
- Seri
- HSE
- Colour
- black
- Thermal Resistance Natural
- 7.50°C/W
- Material
- Aluminum Alloy
