Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Material Cone
- Paper/Foam
- Frequencyselfresonant
- 115Hz
- Empedans
- 8Ohm
- Frequency Range
- 92Hz~7.8kHz
- RoHS Durumu
- RoHS Compliant
- Tip
- General Purpose
- Seri
- CSS
- Efficiency Dba
- 107.00
- Parça Durumu
- Active
- Kurşunsuz
- Lead Free
- Port Location
- Top
- Power Rated
- 10W
- Material Magnet
- Nd-Fe-B
- Shape
- Round, Square Frame
- Ambalaj
- Box
- Terminal
- Solder Eyelet(s)
- Fabrika Tedarik Süresi
- 14 Weeks
- Power Rating
- 10W
- Max Power Dissipation
- 12W
- Maks. Oturma Yüksekliği
- 1.398 35.50mm
- Boyut / Ölçü
- 4.016Lx4.016W 102.00mmx102.00mm
- Efficiency Type
- Sound Pressure Level (SPL)
- Efficiency Testing
- 1W/100mm
- Nem Hassasiyeti (MSL)
- Not Applicable
- Yayın Yılı
- 2016
