Specifications
- Frequencyselfresonant
- 400Hz
- Çalışma Sıcaklığı
- -20°C ~ 70°C
- Frequency Range
- 320 Hz ~ 20 kHz
- Material Magnet
- Nd-Fe-B
- Shape
- Rectangular
- Efficiency Dba
- 94.00
- Empedans
- 8 Ohms
- Tip
- General Purpose
- Terminal
- Solder Pads
- Distortion Rating
- 10% Max @ 1kHz, 1W
- Boyut / Ölçü
- 1.575" L x 0.512" W (40.00mm x 13.00mm)
- Ambalaj
- Tray
- Parça Durumu
- Active
- Efficiency Type
- Sound Pressure Level (SPL)
- Power Rated
- 1 W
- Material Cone
- Polyetheretherketone (PEEK)
- Power Max
- 1.2 W
- Maks. Oturma Yüksekliği
- 0.157" (4.00mm)
- Efficiency Testing
- 1W/100mm
- Port Location
- Top
