Specifications
- Max Power Dissipation
- 2.64W
- Terminal
- 3 Wire Leads
- Nominal Gerilim
- 12VDC
- Boyut / Ölçü
- Square - 60mm Lx60mm H
- Kılıf / Paket
- Axial
- Parça Durumu
- Active
- Bearing Type
- Ball
- Kurşunsuz
- Lead Free
- Akım Değeri
- 170mA
- Rpm
- 5100 RPM
- Min. Çalışma Sıcaklığı
- 14°C
- Material Frame
- Polybutylene Terephthalate (PBT)
- Static Pressure
- 0.228 in H2O (56.8 Pa)
- Fabrika Tedarik Süresi
- 19 Weeks
- Maks. Çalışma Sıcaklığı
- 158°C
- Noise
- 39.0 dB(A)
- Seri
- CFM-60
- Current Rating Amps
- 0.170A
- Material Blade
- Polybutylene Terephthalate (PBT)
- Onay Kuruluşu
- CE, CUR, TUV, UL
- Voltage Range
- 6V~13.8VDC
- Nem Hassasiyeti (MSL)
- Not Applicable
- Çalışma Sıcaklığı
- 14~158°F -10°C~70°C
- Yayın Yılı
- 2017
- Güç (Watt)
- 2.64W
- Özellikler
- Speed Sensor (Tach)
- RoHS Durumu
- RoHS Compliant
- Fan Type
- Tubeaxial
- Genişlik
- 15.40mm
