88974054

Specifications

Depth

68mm

Number Of Inputs

12

Number Of Outputs

8

Montaj Tipi

Chassis Mount, DIN Rail

Mechanical Life

1e+07 cycles

Genişlik

71.2mm

Özellikler

Battery Backup (Lithium)

Number Of Outputs And Type

8 - Relay

Output Current

12A

Seri

Millenium 3, CD20

Expandable

Non-Expandable

Number Of Characters Per Row

18, 18, 18, 18

Çalışma Sıcaklığı

-20°C~70°C

Operating Supply Voltage

24V

Fabrika Tedarik Süresi

3 Weeks

Response Time

5 ms

Uzunluk

100mm

Software

M3 Soft

Montaj

Chassis Mount, DIN Rail, Panel

Yayın Yılı

2011

Display Type

LCD - White Characters, Backlight

Onay Kuruluşu

CE, CSA, GL, UL

Ingress Protection

IP40

Kılıf / Paket

Module

RoHS Durumu

RoHS Compliant

Number Of Inputs And Type

12 - Digital

Nem Hassasiyeti (MSL)

1 (Unlimited)

Terminal

Screw

Parça Durumu

Active

Besleme Gerilimi

24VAC

Memory Size

368Bits/200Words
