Specifications
- Contact Resistance
- 10mOhm
- Parça Durumu
- Active
- Özellikler
- Board Lock, Grounding Indents
- Ambalaj
- Bulk
- Mating Contact Pitch
- 0.09 inch
- Dielectric Withstanding Voltage
- 1000VAC V
- Nominal Gerilim
- 60V
- Yayın Yılı
- 2009
- Material Flammability Rating
- UL94 V-0
- Body Breadth
- 0.509 inch
- Additional Feature
- CLIP,HIGH DENSITY,GND INDENT
- Bodyshell Style
- RECEPTACLE
- Insulation Resistance
- 5000000000Ohm
- Flange Feature
- Board Side (4-40)
- Reference Standard
- UL
- Body Length Or Diameter
- 1.556 inch
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ingress Protection
- IP20
- Shell Size Connector Layout
- 2 DA A High Density
- Insulation Materials
- GLASS FILLED POLYAMIDE
- Connector Style
- D-Sub, High Density
- Body Depth
- 0.291 inch
- Seri
- 163A
- Pozisyon Sayısı
- 26
- Montaj Tipi
- Through Hole
- Çalışma Sıcaklığı
- -55°C~125°C
- Sıra Sayısı
- 3
- Current Rating Amps
- 3A
- Renk
- Black
- Terminal
- Solder
- Contact Finish
- Gold
- Mating Contact Row Spacing
- 0.078 inch
- Contact Materials
- Copper Alloy
- RoHS Durumu
- ROHS3 Compliant
- Shell Material Finish
- Steel, Tin Plated
- Total Number Of Contacts
- 26
- Pcb Contact Pattern
- STAGGERED
- Terminal Adımı
- 2.286mm
- Mounting Option2
- THREADED
- Contact Finish Thickness
- 8.00μin 0.203μm
