Volume pricing
- 1+ pcs$5.79
- 10+ pcs$5.46
- 100+ pcs$5.15
- 500+ pcs$4.86
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Maks. Çalışma Sıcaklığı
- 100°C
- Radyasyon Dayanımı
- No
- Yükseklik
- 27.686mm
- Number Of Elements
- 8
- ECCN Kodu
- EAR99
- Number Of Segments
- 7
- Fabrika Tedarik Süresi
- 13 Weeks
- Display Type
- 7-Segment
- Kılıf / Paket
- 18-DIP (0.600, 15.24mm), 12 Leads
- Terminal Kaplaması
- Tin/Silver/Copper (Sn/Ag/Cu)
- Current Test
- 20mA
- Yayın Yılı
- 2014
- Montaj
- Through Hole
- Dominant Wavelength
- 637 nm
- Forward Current
- 40mA
- Wavelength Peak
- 645nm
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Number Of Characters
- 1
- Forward Voltagemax
- 3V
- Common Pin
- Common Cathode
- Viewing Area Height
- 20.32mm
- RoHS Durumu
- ROHS3 Compliant
- Fonksiyon Sayısı
- 1
- Pin Sayısı
- 18
- Voltage Forward Vf Typ
- 1.8V
- Parça Durumu
- Active
- Character Width
- 11.07mm
- Element Configuration
- Common Cathode
- Min. Çalışma Sıcaklığı
- -40°C
- Character Height
- 20.32mm
- Luminous Intensity
- 14 mcd
- Power Dissipation
- 96mW
- JESD-609 Kodu
- e1
- Boyut / Ölçü
- 1.090 Hx0.786W x 0.330 D 27.69mmx19.96mmx8.38mm
- Depth
- 18.6mm
- Renk
- Red
- Reverse Voltage
- 15V
- Digitalpha Size
- 0.80 20.32mm
