Specifications
- Number Of Elements
- 16
- Number Of Segments
- 7
- Fabrika Tedarik Süresi
- 13 Weeks
- Display Type
- 7-Segment
- Reach Svhc
- No SVHC
- Kılıf / Paket
- 18-DIP (0.600, 15.24mm)
- Maks. Çalışma Sıcaklığı
- 100°C
- Radyasyon Dayanımı
- No
- Yükseklik
- 17.018mm
- Ambalaj
- Bulk
- Kurşunsuz
- Lead Free
- Number Of Characters
- 2
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Common Pin
- Common Anode
- Current Test
- 5mA
- Terminal Kaplaması
- TIN/TIN SILVER COPPER
- Yayın Yılı
- 2005
- Montaj
- Through Hole
- Dominant Wavelength
- 637 nm
- Forward Current
- 20mA
- Wavelength Peak
- 645nm
- Fonksiyon Sayısı
- 2
- RoHS Durumu
- ROHS3 Compliant
- Voltage Forward Vf Typ
- 1.7V
- Pin Sayısı
- 18
- Parça Durumu
- Active
- Viewing Area Height
- 14.22mm
- Operating Supply Voltage
- 1.8V
- Reverse Voltage
- 15V
- Digitalpha Size
- 0.56 14.22mm
- Character Width
- 7.8mm
- Element Configuration
- Common Anode
- Luminous Intensity
- 4.2 mcd
- Min. Çalışma Sıcaklığı
- -20°C
- Character Height
- 14.22mm
- JESD-609 Kodu
- e3/e1
- Boyut / Ölçü
- 0.670 Hx0.990W x 0.315 D 17.02mmx25.15mmx8.00mm
- Power Dissipation
- 37mW
- Renk
- Red
- Depth
- 17.02mm
