Volume pricing
- 1+ pcs$3.95
- 10+ pcs$3.73
- 100+ pcs$3.52
- 500+ pcs$3.32
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Reverse Voltage
- 15V
- Digitalpha Size
- 0.56 14.22mm
- Power Consumption
- 96mW
- Operating Supply Voltage
- 2V
- JESD-609 Kodu
- e1
- Boyut / Ölçü
- 0.670 Hx0.495W x 0.315 D 17.02mmx12.57mmx8.00mm
- Power Dissipation
- 96mW
- Renk
- Red
- Depth
- 17.02mm
- Element Configuration
- Common Cathode
- Luminous Intensity
- 16 mcd
- Min. Çalışma Sıcaklığı
- -20°C
- Character Height
- 14.22mm
- Voltage Forward Vf Typ
- 1.8V
- Pin Sayısı
- 10
- Parça Durumu
- Active
- Fonksiyon Sayısı
- 1
- RoHS Durumu
- ROHS3 Compliant
- Viewing Area Height
- 14.22mm
- Forward Voltagemax
- 3V
- Viewing Angle
- 100 °
- Common Pin
- Common Cathode
- Ambalaj
- Tube
- Kurşunsuz
- Lead Free
- Number Of Characters
- 1
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj
- Through Hole
- Dominant Wavelength
- 637 nm
- Wavelength Peak
- 645nm
- Forward Current
- 100mA
- Current Test
- 20mA
- Terminal Kaplaması
- Tin/Silver/Copper (Sn/Ag/Cu)
- Background Color
- Grey
- Yayın Yılı
- 2010
- Contact Plating
- Copper, Silver, Tin
- Display Type
- 7-Segment
- Reach Svhc
- No SVHC
- Fabrika Tedarik Süresi
- 16 Weeks
- Kılıf / Paket
- 10-DIP (0.600, 15.24mm)
- Number Of Elements
- 8
