Volume pricing
- 1+ pcs$3.87
- 10+ pcs$3.65
- 100+ pcs$3.45
- 500+ pcs$3.25
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Viewing Area Height
- 14.22mm
- Pin Sayısı
- 10
- Parça Durumu
- Active
- RoHS Durumu
- ROHS3 Compliant
- Fonksiyon Sayısı
- 1
- Power Dissipation
- 37mW
- JESD-609 Kodu
- e1
- Boyut / Ölçü
- 0.670 Hx0.495W x 0.315 D 17.02mmx12.57mmx8.00mm
- Depth
- 17.02mm
- Renk
- Red
- Character Width
- 7.8mm
- Element Configuration
- Common Anode
- Min. Çalışma Sıcaklığı
- -20°C
- Character Height
- 14.22mm
- Luminous Intensity
- 4.2 mcd
- Reverse Voltage
- 15V
- Digitalpha Size
- 0.56 14.22mm
- Operating Supply Voltage
- 1.7V
- Yükseklik
- 17.018mm
- Maks. Çalışma Sıcaklığı
- 100°C
- Radyasyon Dayanımı
- No
- Display Type
- 7-Segment
- Reach Svhc
- No SVHC
- Fabrika Tedarik Süresi
- 16 Weeks
- Kılıf / Paket
- 10-DIP (0.600, 15.24mm)
- Power Dissipation Max
- 37mW
- Number Of Elements
- 8
- ECCN Kodu
- EAR99
- Number Of Segments
- 7
- Montaj
- Through Hole
- Dominant Wavelength
- 637 nm
- Forward Current
- 20mA
- Wavelength Peak
- 645nm
- Terminal Kaplaması
- Tin/Silver/Copper (Sn/Ag/Cu)
- Current Test
- 5mA
- Yayın Yılı
- 2001
- Common Pin
- Common Anode
- Kurşunsuz
- Lead Free
- Ambalaj
- Tube
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
