Specifications
- Kurşunsuz
- Lead Free
- Number Of Segments
- 7
- Number Of Characters
- 1
- Radyasyon Dayanımı
- No
- Dominant Wavelength
- 571 nm
- Current Test
- 10mA
- RoHS Durumu
- ROHS3 Compliant
- Common Pin
- Common Anode
- Renk
- Green
- Montaj
- Through Hole
- Forward Voltagemax
- 2.5V
- Pin Sayısı
- 10
- Min. Çalışma Sıcaklığı
- -40°C
- Fabrika Tedarik Süresi
- 13 Weeks
- Reverse Voltage
- 50V
- Kılıf / Paket
- 10-DIP (0.300, 7.62mm)
- Character Width
- 5.59mm
- Ambalaj
- Bulk
- Forward Current
- 30mA
- Fonksiyon Sayısı
- 1
- Terminal Kaplaması
- Tin/Silver/Copper (Sn/Ag/Cu)
- Luminous Intensity
- 3.5 mcd
- ECCN Kodu
- EAR99
- Digitalpha Size
- 0.40 10.16mm
- Operating Supply Voltage
- 2.1V
- Maks. Çalışma Sıcaklığı
- 100°C
- JESD-609 Kodu
- e1
- Power Consumption
- 105mW
- Viewing Area Height
- 10.16mm
- Parça Durumu
- Active
- Wavelength Peak
- 566nm
- Boyut / Ölçü
- 0.508 Hx0.385W x 0.250 D 12.90mmx9.79mmx6.36mm
- Yayın Yılı
- 1996
- Character Height
- 10.16mm
- Display Type
- 7-Segment
- Power Dissipation
- 105mW
- Yükseklik
- 12.9032mm
- Element Configuration
- Common Anode
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Depth
- 9.79mm
