Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Reverse Voltage
- 15V
- Background Color
- Grey
- Row Spacing
- 7.62 mm
- Forward Current
- 15mA
- Reach Svhc
- No SVHC
- Fonksiyon Sayısı
- 1
- Kılıf / Paket
- 14-DIP (0.300, 7.62mm), 10 Leads
- Ambalaj
- Tube
- Character Width
- 10.9mm
- Min. Çalışma Sıcaklığı
- -20°C
- Fabrika Tedarik Süresi
- 13 Weeks
- Pin Sayısı
- 11
- RoHS Durumu
- ROHS3 Compliant
- Current Test
- 5mA
- Montaj
- Through Hole
- Common Pin
- Common Cathode
- Renk
- Red
- Kurşunsuz
- Lead Free
- Number Of Characters
- 1
- Radyasyon Dayanımı
- No
- Dominant Wavelength
- 637 nm
- Element Configuration
- Common Cathode
- Yükseklik
- 19.05mm
- Lead Pitch
- 2.54mm
- Depth
- 12.7mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Power Dissipation
- 37mW
- Number Of Elements
- 8
- Yayın Yılı
- 2006
- Boyut / Ölçü
- 0.750 Hx0.500W x 0.250 D 19.05mmx12.70mmx6.35mm
- Character Height
- 10.9mm
- Wavelength Peak
- 645nm
- Voltage Forward Vf Typ
- 1.7V
- Display Type
- 7-Segment
- Maks. Çalışma Sıcaklığı
- 100°C
- Operating Supply Voltage
- 1.8V
- Parça Durumu
- Active
- JESD-609 Kodu
- e1
- Viewing Area Height
- 10.92mm
- Power Consumption
- 37mW
