Volume pricing
- 1+ pcs$177.25
- 10+ pcs$167.22
- 100+ pcs$157.75
- 500+ pcs$148.82
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Voltage Forward Vf Typ
- 1.5V
- Contact Plating
- Gold
- Fabrika Tedarik Süresi
- 17 Weeks
- Response Time
- 1e-7 ns
- Montaj
- Surface Mount
- Max Power Dissipation
- 200mW
- Giriş Tipi
- DC
- Usage Level
- Military grade
- Turn On Delay Time
- 140 ns
- Yayın Yılı
- 2015
- Inputs Side1side2
- 4/0
- JESD-609 Kodu
- e4
- Besleme Gerilimi
- 5V
- Propagation Delay
- 140 ns
- Output Current Per Channel
- 25mA
- Max Output Current
- 25mA
- Rise Time
- 90ns
- Radyasyon Dayanımı
- Yes
- Propagation Delay Tplh Tphl Max
- 100ns, 100ns
- Optoelectronic Device Type
- LOGIC IC OUTPUT OPTOCOUPLER
- Çalışma Sıcaklığı
- -55°C~125°C
- Ambalaj
- Tube
- Output Current
- 25mA
- Fall Time Typ
- 40 ns
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Pin Sayısı
- 16
- Common Mode Transient Immunity Min
- 1kV/μs
- Montaj Tipi
- Surface Mount
- ECCN Kodu
- EAR99
- RoHS Durumu
- ROHS3 Compliant
- Kılıf / Paket
- 16-Flatpack
- Direction
- Unidirectional
- Hysteresis Rationom
- 0.0125
- Forward Current
- 20mA
- Çıkış Tipi
- Open Collector, Schottky Clamped
- Onstate Currentmax
- 0.025A
- Number Of Elements
- 4
- Rise Fall Time Typ
- 35ns 35ns
- Data Rate
- 10MBd
- Besleme Gerilimi
- 4.5V~5.5V
