Volume pricing
- 1+ pcs$98.10
- 10+ pcs$92.55
- 100+ pcs$87.31
- 500+ pcs$82.37
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Common Mode Transient Immunity Min
- 1kV/μs
- Pin Sayısı
- 8
- Nem Hassasiyeti (MSL)
- 3 (168 Hours)
- Fall Time Typ
- 40 ns
- Output Current
- 25mA
- Ambalaj
- Bulk
- Çalışma Sıcaklığı
- -55°C~125°C
- Optoelectronic Device Type
- LOGIC IC OUTPUT OPTOCOUPLER
- Propagation Delay Tplh Tphl Max
- 100ns, 100ns
- Rise Time
- 90ns
- Radyasyon Dayanımı
- Yes
- Max Output Current
- 25mA
- Output Current Per Channel
- 25mA
- Propagation Delay
- 140 ns
- Besleme Gerilimi
- 5.5V
- Inputs Side1side2
- 2/0
- Yayın Yılı
- 2008
- Turn On Delay Time
- 140 ns
- Usage Level
- Military grade
- Giriş Tipi
- DC
- Max Power Dissipation
- 200mW
- Montaj
- Surface Mount
- Fabrika Tedarik Süresi
- 17 Weeks
- Response Time
- 3.5e-8 ns
- Voltage Forward Vf Typ
- 1.5V
- Additional Feature
- OPEN COLLECTOR, TTL COMPATIBLE, HIGH RELIABILITY
- Reverse Breakdown Voltage
- 5V
- Voltage Isolation
- 1500VDC
- Number Of Channels
- 2
- Parça Durumu
- Active
- Power Dissipation
- 200mW
- Data Rate
- 10MBd
- Besleme Gerilimi
- 4.5V~5.5V
- Rise Fall Time Typ
- 35ns 35ns
- Number Of Elements
- 2
- Çıkış Tipi
- Open Collector, Schottky Clamped
- Forward Current
- 20mA
- Hysteresis Rationom
- 0.0125
- Direction
- Unidirectional
- Kılıf / Paket
- 8-CSMD, Gull Wing
