Volume pricing
- 1+ pcs$7.84
- 10+ pcs$7.40
- 100+ pcs$6.98
- 500+ pcs$6.59
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Output Voltage
- 30V
- Rise Fall Time Typ
- 100ns 100ns
- Propagation Delay
- 500 ns
- Onay Kuruluşu
- CSA, IEC/EN/DIN, UR
- Current Dc Forward If Max
- 25mA
- Max Output Current
- 600mA
- Usage Level
- Industrial grade
- JESD-609 Kodu
- e3
- Max Input Current
- 400mA
- Additional Feature
- UL RECOGNIZED, VDE APPROVED
- Parça Durumu
- Active
- Common Mode Transient Immunity Min
- 15kV/μs
- Kurşunsuz
- Lead Free
- Rise Time
- 100ns
- Fabrika Tedarik Süresi
- 22 Weeks
- Propagation Delay Tplh Tphl Max
- 500ns, 500ns
- Ambalaj
- Tube
- Direction
- Unidirectional
- Montaj Tipi
- Surface Mount
- Fall Time Typ
- 100 ns
- Voltage Forward Vf Typ
- 1.6V
- Optoelectronic Device Type
- LOGIC IC OUTPUT OPTOCOUPLER
- Number Of Channels
- 2
- Reach Svhc
- No SVHC
- RoHS Durumu
- ROHS3 Compliant
- Input Current
- 16mA
- Yayın Yılı
- 2003
- Pin Sayısı
- 16
- Number Of Elements
- 2
- Pulse Width Distortion Pwd
- 300 ns
- ECCN Kodu
- EAR99
- Montaj
- Surface Mount
- HTS Kodu
- 8541.40.80.00
- Kılıf / Paket
- 16-SOIC (0.295, 7.50mm Width), 12 Leads
- Max Power Dissipation
- 295mW
- Configuration
- COMPLEX
- Terminal Kaplaması
- Matte Tin (Sn)
- Voltage Isolation
- 5000Vrms
- Supply Voltagemin Vsup
- 15V
